Used as fixed installation cables in various electromechanical and electronic equipments, emergency and critical systems as well as electric distribution and lightning systems.
| Conductor | : | Electrolytic, stranded, tinned copper wire /EC 60228 Class 2 |
| (Class 5 on request) | ||
| Seperator | : | Mica tape over conductor |
| Insulation | : | Halogen free EPR or Halogen free HEPR |
| Outer Sheath | : | SHF2 (SHF MUD on request) |
| Construction | : | NEK 606 P17, IEC 60092/353 |
| Tests And Material | : | IEC 60092 /350-351-359 |
| Flame Retardant | : | IEC 60332 /1, IEC 60332 / 3 Cat A |
| Fire Resistant | : | IEC 60331 |
| Halogen Content | : | IEC 60754 / 1 – 2 |
| Smoke Density | : | IEC 61034 / 1-2 ( DIN EN 50268/1-2) |
| Working Temperature | : | -40°C / + 90°C |
| Min. Bending Radius (fixed) | : | 7 x (overall diameter) |
| Rated Voltage | : | 0,6 / 1 kV |
| Test Voltage | : | 3,5 kV |
