Energy distribution cable for fixed installation in buildings, for direct laying in concrete, water and under ground. The concentric conductor is allowed to be used for screening purposes.
| Conductor | : | Plain copper conductor, to IEC 60228 cl.1 or cl.2 solid or stranded type |
| Colour coded to DIN VDE 0293 | ||
| Core colour for 3+ 1/2 conductor | ||
| J-type: gnye (1/2), bn, bk, gy | ||
| O-type: bu (1/2), bn, bk, gy | ||
| PVC self-extinguishing and flame retardant according to IEC 60332-1B | ||
| Insulation | : | PVC core insulation, DIV4 |
| Cores stranded concentrically conductor in inner layer of round copper wires, | ||
| Outer layer with copper tape | ||
| Sheath | : | Sheath colour black |
| Outer Jacket | : | PVC outer jacket |
| Standard | : | Power and control cable IEC 60502 |
| Temperature range | : | Flexing: -5°C to +60°C |
| Fixed installation: -30°C to +70°C | ||
| Nominal voltage | : | Uo/U 0,6/1kV |
| Test voltage | : | 4kV |
| Minimum bending radius | : | for single core approx. 15 x cable Ø |
| for multi core approx. 12 x cable Ø |
